- OS
- Android 7.0 (Nougat)
- Design
-
- Size
- 278 x 202 x 76 mm
- Weight
- 2.3kg
- Finishing
- High-quality anodized aluminum front-top with modern sense
- Display
- Wide view 8.8" multi touch screen
- Power
-
- Maximum output
- 100W
- Speaker impedance
- 4~16 Ω
- Wireless
-
- Network
- Ethernet 10/100/1000 BASE-T
WiFi (802.11 b/g/n/a/ac) 2.4Ghz/5Ghz Dual Band
- Bluetooth
- Bluetooth 4.0 (AD2DP SINK, AVRCP)
- Streaming
- Airplay / DLNA Service
- Input, Output
-
- Audio input
- Connections for source devices such as CD/ DVD /Blu-ray Player
S / PDIF connections for TV, Projector, CD / DVD / Blu-ray Player
- Audio output
- Headphone Out : Connection for 3.5mm headphone
PreAmp Out : Connection for vacuum tube amplifier, reference amplifier
Speaker Out : Connection for L+/L-, R+/R- speaker
Optical Out : S / PDIF connections for sound bar
- video output
- HDMI connections for TV, Projector
- Media connection
- USB 2.0 x 1, USB3.0 x 1 (File system - NTFS/FAT32, Supported capacity - 512GB, External HDD by 4TB)
MicroSD x 1 (File system -NTFS/FAT32, Supported capacity - 512GB) SATA3.0 SSD x 1 (File system - NTFS, Supported protocol - FTP/WebDav, 4TB)
USB C type x 1 (Only for service)
- Supported codec
-
- Audio
- MQA, WAV, FLAC, WMA, MP3, APE, DFF, DSF, AAC, CDA, AMR, APE, EC3, E-EC3, MID, MPL, MP2, MPC, MPGA, M4A
PCM : 8KHz~384KHz(8/16/24/32bit per Sample)
Native DSD: DSD64(2.8MHz)/DSD128(5.6MHz)/DSD256(11.2MHz)
- Video
- ASF, AVI, MKV, MP4, WMV, MPEG-1, MPEG-2, MPEG-4 H.263, H.264, H.265, VC-1, VP9, VP8, MVC
H.264/AVC, Base/Main/High/High10 profile@level5.1 up to 4Kx2K@30fps
H.265/HEVC, Main/Main10 profile@ level 5.1 High-tier up to 4Kx2K@60fps
- Power
-
- Input power
- AC100-240V, 50/60Hz
- Output power
- DC 24V, 5.0A
- Standby power
- Standby mode<0.5W
- Update
- SW update via internet, manual update via USB
- Remote control
-
- Remote controller
- BT Remote controller
- Remote App
- ROSE Connect (Android, iOS)
- Accessory
- AC adpater x 1, Quick guide x 1, BT Remote controller x 1, Battery (AAA) x 2, Screw for SSD x4, Screw driver x 1
|
